　　Air purifiers, also known as air filters, can filter out impurities in the air and output clean air. In this era of industrial pollution and severe smog, air purifiers have become essential equipment widely used in homes, hotels, and other places. It consists of three parts: control circuit, mechanical and detection status indication. The mechanical part involves the fan motor passing indoor air through a filter and circulating impurities to achieve air purification.

　　The core of an air purifier is a small motor. In this transmission system mechanism, small motors are prone to overload or rotation due to problems such as mechanical lack of lubricating oil, bearing wear, rust, dust, etc., ranging from burning out the motor to burning out the motor and wires, and even leading to fire accidents. So it is necessary to design overload protection and gambling protection circuits for the motor to ensure safe operation.

　　Traditional designs often use bimetallic temperature controllers as over temperature protection for motors. Due to the high current of the motor after overload or rotation, the temperature rapidly increases. When the bimetallic temperature controller senses high temperature, it disconnects the circuit. But the bimetallic temperature controller will not remain disconnected after disconnecting the circuit. After the circuit is disconnected, there is no current, and the motor temperature gradually decreases. The temperature controller will connect the motor that has already been rotated again, and the motor will cycle to start. When the motor continues to heat up, the temperature controller will protect it again, and this cycle will operate. If the user cleans up foreign objects after the motor is rotated or the motor suddenly runs during inspection, it can cause personal injury and other accidents. The bimetallic thermostat is only designed for temperature, not for current. The high current after the motor rotates repeatedly, which can burn out its control circuit. Moreover, aluminum wire or copper clad aluminum wire are now used to wind the motor, which causes faster temperature rise. It is possible that the thermostat has not been disconnected yet and the motor coil has been burned out.

　　For this reason, we recommend using the self restoring fuse PolySwitch PPTC (Positive Temperature Coefficient Thermistor) for overload protection and locked rotor protection of the motor, so that there will be no negative consequences or disasters caused by repeated motor starts. The self restoring fuse can complete both overcurrent protection and temperature protection, and will maintain this protection state until the power is turned off before restoring to the initial state.

　　The use of self recovery fuses for motor stall protection and over temperature protection is a cost-effective protection scheme. Under fault conditions such as short circuit, overcurrent, over temperature, and motor stall, the PPTC device can quickly change from low resistance state to high resistance state compared to dual metal temperature controllers under the dual action of high current and high temperature rise, and can timely limit the current of the motor to protect the motor and equipment system. And maintain this protective state all the time, only after power outage will the self restoring fuse recover from high resistance state to low resistance state. The continuous self recovery fuse cannot be restored, which can effectively avoid various potential problems and safety hazards that may occur with the automatic air purifier mentioned above.
