| Breaking Capacity | Material | Operating Temperature | Soldering conditions |
| 50A at 32V DC(250mA-5A) | Substrate - Ceramic Termination-Sliver over-plated with nickel and tin Element--Silver | -40℃~+125℃ | Wave solder: 260℃, ≤5S Hand solder: 360℃, ≤1S |
| Amper Rating | Testing current | Blow Time | |
| Min | Max | ||
250mA~5A | 100% | 4 hours | - |
| 250mA~5A | 200% | 1s | 60s |
| 250mA~5A | 250% | - | 5s |
● Pending
○ Approvals
| Current Rating | Voltage Rating | Marking | Norminal Melting I²T(A²sec) For Reference | Approvals | |
 |  | ||||
| 250mA | 32V | D | 0.0005 | ● | |
| 375mA | 32V | E | 0.001 | ● | |
| 500mA | 32V | F | 0.004 | ● | |
| 750mA | 32V | G | 0.009 | ● | |
| 1A | 32V | H | 0.011 | ● | ○ |
| 1.25A | 32V | J | 0.02 | ● | ○ |
| 1.5A | 32V | K | 0.07 | ● | ○ |
| 2A | 32V | N | 0.19 | ● | ○ |
| 2.5A | 32V | O | 0.25 | ● | ○ |
| 3A | 32V | P | 0.28 | ● | ○ |
| 3.5A | 32V | R | 0.56 | ● | ○ |
| 4A | 32V | S | 0.95 | ● | ○ |
| 5A | 32V | T | 1.87 | ● | ○ |
