　　Low zero power resistance: The self resetting fuse has low impedance, low power loss during normal operation, and low surface temperature.

　　Fast overcurrent protection speed: Due to its material characteristics, the self resetting fuse has a much faster response speed to overcurrent conditions than other overcurrent protection devices.

　　Self locking operation: The self resetting fuse is in an overcurrent protection state, locked in a high resistance state with minimal current. Only after cutting off the power supply or the overcurrent disappears, can the low resistance state be restored.

　　Automatic reset: The self resetting fuse resets itself after providing overcurrent protection (troubleshooting), without the need for replacement.

　　High current resistance: Self restoring fuses have excellent high current resistance, and some specifications can withstand 100A current impact.

　　Application: PPTC has a wide range of applications and can be used in various electronic products, communication products, power supplies, etc.
