overheat protection device.What is the model of commonly used patch fuses?

04

2023-12

Share:

　　27b20fe97d2023d

　　Chip fuses can be divided into 9 categories based on their volume size: 0402 volume, 0603 volume, 0805 volume, 1206 volume, 1210 volume, 1812 volume, 2410 volume, 2920 volume, and 4012 volume. The most commonly used volumes for SMD fuses are 1206, 18122410, and 0603, followed only by a small amount of remaining volume.

　　The commonly used models for SMD self recovery fuse 1206 include ASMD1206-020 (0.2A/24V), ASMD1206-025 (0.25A/16V), ASMD1206-050 (0.5A/6V), ASMD1206-050-16V (0.5A/16V), ASMD1206-050-24V (0.5A/24V), ASMD1206-075 (0.75A/6V), ASMD1206-100 (1A/6V), ASMD1206-150 (1.5A/6V), ASMD1206-200 (2A/6V), and ASMD1206-300 (3A/6V).

　　The commonly used models for SMD self recovery fuse 1812 include ASMD1812-010, ASMD1812-020, ASMD1812-050, ASMD1812-050-30, ASMD1812-075, ASMD1812-110, ASMD1812-110-16, ASMD1812-150, ASMD1812-200, ASMD1812-300, and ASMD1812-350.

　　The commonly used models for SMD self recovery fuse 0603 are ASMD0603-010, ASMD0603-020, ASMD0603-050, and ASMD0603-075.

　　The commonly used models for disposable patch fuse 1206 in volume include JFC1206-1150, JFC1206-1200, JFC1206-1350, JFC1206-1400, JFC1206-1500, JFC1206-2100, JFC1206-1700, and JFC1206-1800.

　　The commonly used models for disposable patch fuse 2410 include JFC2410-1100, JFC2410-1150, JFC2410-1200, JFC2410-1250, JFC2410-1500, JFC2410-1400, JFC2410-1600, JFC2410-1630, JFC2410-2150, JFC2410-2200, and JFC2410-1800.
