　　Can surge thyristors and discharge tubes only be used for transient overvoltage protection, while polymer positive temperature coefficient self recovery fuses can only be used for overcurrent protection? So what is the maximum current and voltage they can withstand?

　　Generally speaking, traditional overvoltage protection devices are mainly used for transient overvoltage protection, but they are also suitable for long-term voltage stabilization conditions that do not exceed their rated power.

　　Self recovery fuses can not only be used for overcurrent protection, but also for temperature protection or protection under the combined action of current/temperature. In addition, they can also be used in conjunction with IC for temperature detection and feedback of temperature signals for protection.

　　At present, the maximum voltage that the self recovery fuse can withstand is 600Vrms, and the maximum holding current is 15A; The maximum voltage of PPTC for automobiles is 60Vdc, and the maximum holding current is 15A.
