　　Our self recovery patch fuse 1206 series has a size of 3.2 * 1.6mm, SMD packaging, reel packaging, and a packaging of 3000 pieces. The withstand voltage value ranges from 6V-60V, with a maintenance current of 0.05A-3.5A. As the maintenance current increases, the withstand voltage value also decreases relatively, and the temperature control range is -40+85 ℃.

　　Generally, our fuse testing is conducted at room temperature. When customers actually use it on a board, they should also consider the impact of temperature on the internal resistance of the fuse. Generally speaking, as the temperature increases, the internal resistance also increases, and the speed of fuse protection will also be relatively faster.

　　The volume of 1206 patch is a commonly used volume for patch self recovery fuses, as it is not as large as the volume of 1812, and is also compared to the volume of 0603 and 0805, which can achieve a wider current range and higher voltage withstand value.

　　Our ASMD1206 series is generally used for USB peripheral devices, hard drives, CD drives, handheld alarms, electric toy cars, plug and play protection devices for motherboards and peripheral devices, and more.
