　　A professional enterprise engaged in the research and development, production, and sales of patch fuses and plug-in fuses. All products meet the requirements of lead-free and halogen-free environmental protection, and have obtained foreign authoritative safety certification such as UL, VDE, TUV, etc. The products are widely used in industries such as computers, communication, security, automobiles, toys, and household appliances.

　　Main supply products: self recovery fuses, disposable fuses, patch fuses, plug-in fuses, Litteluse Litteluse fuses.

　　The miniature fuse meets the following conditions:

　　1. Power on capacity: Power on at rated current for 1 hour without fusing.

　　2. Temperature rise: When energized according to the rated current, the ground temperature rise is less than 75 ℃.

　　3. Fusing test: Fusing within 1 minute at twice the rated current.

　　4. Breaking capacity: When the rated breaking capacity is added, there will be no continuous arcing or ignition.

　　This product can be applied in battery chargers, consumer electronics, power supply, industrial controllers, chargers, and some special small circuit space devices.
