| Breaking Capacity | Material | Operating Temperature |
| 50KA mperes at 690V AC (10A-100A) | Fuse body -- ceramic tude End -- Silver plated brass Pigtail -- tin plated copper on nickel plated brass cap | -40℃~+125℃ |
| 20KA mperes at 690V DC (10A-100A) |
| Testing current | Blow Time | |
| Min | Max | |
| 400% | 100ms | 10s |
| 100% | 4H | - |
● Pending
○ Approvals
| Current Rating | Voltage Rating | Approvals | ||
 |  |  | ||
| 10A | 690V | ○ | ○ | ○ |
| 12A | 690V | ○ | ○ | ○ |
| 15A | 690V | ○ | ○ | ○ |
| 20A | 690V | ○ | ○ | ○ |
| 25A | 690V | ○ | ○ | ○ |
| 30A | 690V | ○ | ○ | ○ |
| 32A | 690V | ○ | ○ | ○ |
| 40A | 690V | ○ | ○ | ○ |
| 50A | 690V | ○ | ○ | ○ |
| 60A | 690V | ○ | ○ | ○ |
| 63A | 690V | ○ | ○ | ○ |
| 70A | 690V | ○ | ○ | ○ |
| 75A | 690V | ○ | ○ | ○ |
| 80A | 690V | ○ | ○ | ○ |
| 90A | 690V | ○ | ○ | ○ |
| 100A | 690V | ○ | ○ | ○ |
